Core Products & Technology
Our range covers brake, speedometer, sideslip, suspension and emissions testing, combining intelligent control and data acquisition for precise, efficient vehicle inspection.
Brake & Axle/Wheel Load Testing Equipment
The CTFZ-10D combines a mobile roller brake tester, access ramps, wireless controls and a laptop for projects that move between testing locations. The supplied configuration requires confirmation of deployment conditions and the precise meaning of its listed 10 t rating.
View Details
Chassis Dynamometer & Power Testing Equipment
The CTDCG-3J and CTDCG-3-4WD chassis dynamometers measure wheel power, torque and tractive effort under controlled road loads. Air-cooled eddy current absorbers support constant-speed, constant-traction and acceleration testing, with 1,000 hp 2WD and 2,000 hp AWD configurations. The AWD model adds adjustable wheelbase positioning for conventional, hybrid and electric powertrains.
View Details
Brake & Axle/Wheel Load Testing Equipment
The CTGT-3-3 combines brake, axle-load and sideslip testing with computer control, selectable operating modes, brake-force curves and consolidated reports. Wheel-load measurement, double-plate sideslip and additional instruments can be specified separately.
View Details
Brake & Axle/Wheel Load Testing Equipment
The CTGT-3-4 series integrates brake, suspension, load and sideslip testing under industrial-computer control, with response curves, consolidated reports and searchable records. Single- and double-plate sideslip versions support different project configurations.
View Details
Suspension, Chassis & Steering Testing Equipment
The CTZJ-13-2 measures left and right steering angles under vehicle load, using motorized turntable positioning to accommodate different wheel tracks. Its floating plates allow natural wheel movement, while pneumatic locking and automatic zero return protect the mechanism during vehicle passage. A 13,000 kg axle capacity supports heavy-vehicle inspection lanes.
View Details
Wheel, Tire & Vehicle Dimension Inspection Equipment
The CTLT series scans tire tread with non-contact line lasers as vehicles drive over the platform, measuring groove depth and identifying uneven wear without wheel removal. Automated reports, replacement alerts and same-axle tire consistency checks support routine inspections, with 3,000 kg or 15,000 kg axle-load models and surface-mounted or flush installation options.
View Details
Lighting & Emission Testing Equipment
The ML-100 measures diluted exhaust flow, oxygen concentration, temperature and pressure for simple transient emissions testing. Ultrasonic and vortex flow measurement combines with a zirconia oxygen sensor to supply the data needed for pollutant mass calculations. A three-minute warm-up and RS-232 output support integration into automated inspection lanes.
View Details
Lighting & Emission Testing Equipment
The MQW exhaust gas analyzer range offers model-specific configurations for gasoline, diesel and motorcycle emissions testing. NDIR, electrochemical and UV measurement options cover different gas combinations and test cycles, from dual-idle checks to loaded transient testing. Selected models add fast-response sampling, NOx conversion or direct smoke-meter connection for integrated emissions assessment.
View Details
Suspension, Chassis & Steering Testing Equipment
The CTZN-3 evaluates suspension damping without removing shock absorbers, using independently driven vibration plates and automatic vehicle detection. Computer analysis presents damping values, oscillation curves and left-to-right differences to help identify worn components and uneven suspension performance. The excitation cycle also helps technicians locate chassis noise during passenger-vehicle inspections.
View DetailsProduct Selection
Share your vehicle types, inspection scope, applicable standards, target throughput and site conditions.
Discuss Your Project
